SPECIFICATIONS
General Parameters
- Recommended user: Infants weighing up to 10 kg
- Operational environmental conditions: Temperature 18°C ~ 40°C, humidity 5% ~ 95%
- Storage and transportation conditions: Temperature -40°C ~ 60°C; humidity up to 95%; atmospheric pressure 50 ~ 106 kPa
- Protection against water ingress: IPX4
- Total weight (including resuscitator and accessories): ≤ 6 kg
- Dimensions (mm): 290 (L) x 180 (W) x 370 (H)
System Parameters
- Gas supply: Medical oxygen and air (from a pressurized gas pipeline system or pressurized gas cylinder)
- Gas inlet pressure range: 300 ~ 500 kPa (approximately 45 ~ 75 Psi)
- Gas flow rate: ≥ 50 L/min
- Alarm: Single gas source failure alarm
- Low pressure unit for medical use – pressure range: 0 ~ 1000 kPa
- Low pressure unit for medical use – flow range: 160 ~ 500 L/min
Air/Oxygen Mixing Function
- Oxygen concentration setting range: 21% ~ 100%
- Accuracy: ≤ ±3% V/V
- Back gas flow: In accordance with ISO 11195:1995 regulations
- Gas flow rate range: 0 ~ 15 L/min, with setting levels at 0.5, 1, 2, 3, 4, 5, 6, 8, 10, 12, 15 (L/min)
- Gas flow rate accuracy:
- ±0.5 L/min at 0.5, 1, 2, 3, 4 L/min
- ±1 L/min at 5, 6, 8, 10 L/min
- ±2 L/min at 12 and 15 L/min
